If your Xhorse Dolphin II XP-005L is not holding a charge like it used to, shutting down unexpectedly, or simply has an aging battery, replacing the battery may be the next step.
The good news is that the process is fairly straightforward. You do not need a full bench of specialty tools, just a compatible replacement battery, a 2.5 mm hex key, and a little patience while working through the panels and connectors.
Watch the XP-005L Battery Replacement
Want to see the complete process before opening your machine? Oscar from the Locksmith Keyless Repair Center demonstrates the XP-005L battery replacement, including panel removal, battery disconnection, installation, and reassembly.
What You'll Need
- A compatible replacement battery for the Xhorse Dolphin II XP-005L
- A 2.5 mm hex key
- A clean, stable workspace
- A small container or organizer for keeping screws together
Before starting, power the machine off and disconnect it from any external power source.
Safety note: Handle the battery carefully and avoid puncturing, crushing, or short-circuiting it. Do not pull directly on battery wires or connectors. If the battery appears swollen, damaged, or leaking, do not continue with the replacement procedure.
Step 1: Remove the Side Panels
Start with the two side panels on the XP-005L. Use the 2.5 mm hex key to remove the screws securing each panel.
Work on one side at a time and place the screws somewhere safe as you remove them. Once both side panels are off, you can move on to the lower section of the machine.
Step 2: Remove the Lower Cover
Place the XP-005L carefully on its side.
Before removing the lower cover, take off the upper front foot. This gives you access to the screws holding the lower panel in place.
Remove the screws securing the lower panel using the 2.5 mm hex key, then carefully lift the panel away.
Once the cover is removed, the battery will be exposed.
Step 3: Remove the Old Battery
The battery is held in place by four screws, two at the top and two at the bottom.
Remove all four screws using the same 2.5 mm hex key.
Next, disconnect the four electrical connections at the back of the battery. Take your time here and avoid pulling directly on the wires. Disconnect each plug carefully from its connector.
Once all four connections are unplugged, the old battery can be removed from the machine.
Step 4: Install the New Battery
Installing the replacement battery is essentially the reverse of the removal process.
Position the replacement battery inside the machine and reconnect the four plugs. Make sure each connection is fully seated before continuing.
Once everything is connected, align the battery with its mounting points.
Repair Center tip: Install the top battery screws first. This helps stabilize the battery while you align the remaining mounting points and install the other screws.
Tighten the screws until they are snug, but avoid overtightening them.
Step 5: Reassemble the XP-005L
With the replacement battery secured, reinstall the lower cover.
Replace the screws using the 2.5 mm hex key, then reinstall the front foot that was removed earlier.
Next, reinstall both side panels and secure their screws.
Before powering the machine on, give everything a quick visual inspection to make sure the panels are properly seated and no screws or connectors were left loose.
Step 6: Power It On and Test the Battery
Once the XP-005L is fully reassembled, turn the machine on.
Confirm that it boots normally and check the battery level. If the replacement was installed correctly, the machine should operate normally and begin reporting the new battery's charge level.
Tips for Replacing the XP-005L Battery
- Keep screws from each panel grouped together to make reassembly easier.
- Do not overtighten the screws when reinstalling the battery or covers.
- Handle battery connectors carefully and avoid pulling on the wires themselves.
- Make sure every connector is fully seated before closing the machine.
- Inspect the battery and connectors for visible damage before installation.
- If the machine still has power or charging issues after replacement, the battery may not be the only component involved.
When Should You Consider Replacing the XP-005L Battery?
Battery performance naturally declines over time. Replacement may be worth considering if you notice significantly shorter operating time, the machine struggling to hold a charge, unexpected shutdowns, or a battery that no longer reaches normal capacity.
That said, battery replacement should not automatically be the first fix for every power-related issue. Charging hardware, connectors, power circuitry, or other components can produce similar symptoms.
Frequently Asked Questions
How do I know if my XP-005L battery needs replacement?
Shorter operating time, difficulty holding a charge, unexpected shutdowns, or a battery that no longer reaches its normal capacity can indicate that the battery is aging. However, similar symptoms can also be caused by charging hardware, connectors, or other components.
What size hex key is needed to replace the XP-005L battery?
A 2.5 mm hex key is used for removing and reinstalling the screws during the battery replacement procedure.
Can I replace the XP-005L battery myself?
The battery replacement procedure is relatively straightforward if you are comfortable working carefully with electronic equipment. The process involves removing the machine's panels, disconnecting the existing battery, installing the replacement, and reassembling the machine. Always power the machine off and disconnect it from external power before beginning.
Final Thoughts
Replacing the battery on the Xhorse Dolphin II XP-005L involves removing the side panels and lower cover, disconnecting the existing battery, installing the replacement, and carefully reassembling the machine.
Taking time to organize the screws, handle the battery connectors carefully, and verify every connection before powering the machine back on can help make the process smoother and avoid unnecessary issues.
If you work with Xhorse equipment regularly, knowing basic maintenance procedures like this can help reduce downtime and keep your key-cutting equipment ready for the job.
