AVDI Plus is the latest hardware upgrade of the trusted Abrites main diagnostic interface. It delivers improved performance and adds support for modern communication protocols such as CAN-FD and Ethernet, ensuring compatibility with the evolving automotive industry, while still retaining legacy interfaces and full support for most existing Abrites hardware accessories.

Features:

• CAN-FD Connectivity - Controller Area Network Flex Data Rate included for future development. Creates a basis for continuous upgrade.
• ENET - Ethernet included in the interface. Reduces procedure time by utilizing faster communication.
• Futureproof - Opens the door for continued development and constant evolution and development of the Abrites software.
• Reliability - Same reliability and strength with greatly improved performance.

Specifications:

• K-line ISO 9141 (100 mA) multiplexed to 24 different pins of the diagnostic connector.
• ISO14230 compliant.
• SAE J1850 VPW, PWM compliant (additional adapter required).
• Single wire CAN bus multiplexed to different pins of diagnostic connector.
• Dual wire low speed CAN bus multiplexed to different pins of diagnostic connector.
• Dual wire high speed CAN bus multiplexed to different pins of diagnostic connector.
• CAN bus GMLAN, ISO14229, ISO15765, J1939, ISO22901 compliant.
• Analog Input USB interface to the PC Supply voltage 8..30V DC OBDII cable.
• Updatable firmware.

Standard Diagnostics:

• Full vehicle scan - scan cars, vans, trucks, and heavy-duty vehicles with one click
• Module identification - AVDI reads and identifies all available modules in the vehicle and the data they store, e.g. VIN and part numbers (where applicable)
• Reading and clearing diagnostic trouble codes (DTCs), a.k.a. faults
• Live values display - get live data information from the sensors in the vehicle in real time, e.g. temperature, RPMs, and more
• Actuator testing - identify any possible issues in the car by performing actuator tests
• Coding operations

More Functionalities in the Essential Software:

(where applicable)

• Module adaptation
• Reset/renewal of second-hand modules
• Key and transponder programming
• Instrument cluster calibration
• Airbag renewal
• Change software version of modules (updates)

Advanced Diagnostics:

(Brand-Specific)

• Calibrations
• Configuration settings
• Coding options
• Diagnostic channel adaptations
• Guided functions
• Hundreds more

AVDI is your gateway to professional vehicle diagnostics. It is compatible with more than 40 automotive brands, offering your workshop a wide range of opportunities

• Key and transponder programming: in ALL KEYS LOST situations and spare key addition
• Cluster calibration: dashboard calibration for replacement and retrofitting purposes
• Module reset: renew second-hand units to use as replacement of faulty ones
• Module adaptation: adapting new and used modules in various types of vehicles
• ECU-related procedures: working with a vast array of Engine Control Units (reading and writing data)

Basic User Diagnostic Software:

• BR002 - VCINPL B.U.D.S

BIKES:

• BK002 Advanced bike diagnostics, BMW Bikes key programming

BMW:

• BN007 - EBridge Tool

CHRYSLER:

• CR007 - Engine Control Unit Flash Manager
• Read/write Data Flash and Program Flash for EDC15C2 and EDC16CP31 ECUs

DAF:

• DF002 - Key Programming

ECUPROG:

• EP001 - Bosch EDC17/MED17, Delphi, SIMxx
• EP003 - ECU and TCU Manager

FIAT/LANCIA/ALFA ROMEO:

• FN007 - Transponder Maker
• FN008 - Key Learning
• FN011 - BCM Read/Update
• FN012 - BCM and Key Manager
• FN013 - Instrument Cluster Data Manager
• FN014 - Engine Control Unit Flash Manager
• FN017 - PIN and Key Manager for FCA vehicles

FORD:

• FR005 - Instrument Cluster Module Recalibration
• FR008 - Key Manager, Advanced Diagnostic Functionality
• FR009 - Airbag
• Airbag clear crash data and renew - RCM module with the following processor: XC23xx data flash for FORD/Mazda/JLR and Volvo, as well as TMS470 + EEPROM 25320/25640 for Ford/JLR

MAZDA

• MZ001 - Key programming for Mazda 3/CX-30 2020+
• MZ002 - PATS initialization for Mazda 3/CX-30 2020+

HYUNDAI/KIA:

• HK007 - Instrument Cluster, Engine Control Data Manager

JLR:

• JL002 - Key Learning
• JL003 - Cluster Calibration
• JL004 - Key Learning (DPLA, FK72, HPLA)
• JL005 - Key learning (2018-2020)

MERCEDES/MAYBACH/SMART:

• Mercedes Online- CPC modifications by OBDII - VMAX limiter removal/ Exhaust flaps adjustment/ Torque limiter adjustment
• SCN coding completely by OBDII by using Mercedes Online (no Xentry online account is required)
• MN002 - Cluster Calibration by OBD (K-Line), Assyst Plus ( Mileage calibration - both SAM module and instrument cluster)
• MN003 - Airbag (Clear crash data from Bosch/Temic/TRW airbags up to 2010)
• MN004 - TV/AUX, Seatbelt, Reverse warning, Gulf states (Enable Video in Motion - either by using Mercedes Offline or Mercedes Online)
• MN005 - Key Programming, Immo read/update (Key programming by dump (DAS 2/2a/2b)
• MN006 - ECU Read/Update Flash
• MN007 - CGW (Central Gateway) Read/Update ConfData (SOFTOUCH activation - switching from semi-automatic to automatic transmission), Gearbox adaptation
• MN008 - SMART Key Learning, Emergency start - models 451, 454 ( Key programming - models 450, 451, 452, 454 ), Cruise control activation
• MN009 - Cluster Calibration for SMART after 2007
• MN010 - Cluster Calibration for S-Class W221/CL W216 and Sprinter, Vito, Viano (after 2006)
• MN011 - CAN Dash Cluster Calibration - W211, W219, W164, W251, W203...
• MN012 - Cluster Calibration - Mercedes, Smart
• MN013 - Airbag - clear crash data
• MN014 - Cluster Calibration in Dash in SMART 2007+ and in SAM module (451)
• MN015 - Cluster Calibration - Mercedes
• MN016 - Cluster Calibration for W204/W212/W207/W197/X204/w218
• MN017 - Cluster Calibration for W220/W215; Read/Update ConfData of W220/W215/W169/W245/W221/W216 (Reflashing and renewal of SAM module and SAM/ECM synchronisation), Cluster calibration and adaptation for vehicles up to 2014
• MN018 - Key Learning (DAS2, DAS2A, DAS2B, DAS3), Virgin ECU, SBC Repair (SBC counter reset), Repair Start Error
• MN019 - Electronic Transmission Control (722.9) and ISM renew ( 7-G Tronic Databse for TCU reflashing)
• MN020 - Instrument Cluster Data Manager ( Mileage calibration )
• MN021 - TV (TV In Motion), ECU, Airbag Manager
• MN026 - Key Programming, EIS/ESL/DAS Manager/7-Gear ETC/ISM/Infra Red and password reader/Personalization/Activation/Coding
• MN028 - Instrument Cluster Data Manager, TV (TV In Motion), ECU, Airbag Manager

MITSUBISHI:

• MI002 - Key Learning
• MI003 - ECU Read/Update Flash - Reading of EDC15 engine control units (ECU)
• MI005 - Electronic Control Unit reprogramming ( EDC15 engine control units (ECU) reprogramming)
• MI006 - PIN and Key Manager
• MI007 - PIN and Key Manager

OPEL:

• ON007 - Tech2Win Driver
• ON010 - Engine Control Unit Flash Manager

RENAULT:

• RR002 - Key learning
• RR003 - ClioIII, Modus, MasterIII, Logan, Traffic
• RR005 - Key learning
• RR006 - Megane III key learning
• RR007 - Updated SW key learning
• RR008 - Clio IV key learning
• RR010 - Clio IV key learning
• RR012 - Twingo III key learning
• RR015 - Smart 453 key learning

SUBARU:

• SB001 - Subaru Key learning and smart system reset

TAGPROG:

• KT001 - Tag Key Tool programmer 55105509
• KT002 - Key Maker Q7/A6/Allroad
• KT003 - Key Maker Passat B6/CC
• KT004 - Key Maker ClioIII/Duster
• KT005 - VAG Tp22/Tp23/Tp24/Tp25 production
• KT006 - Key Maker Passat B6/CC Keyless
• KT010 - Tag Key Tool
• KT012 - Porsche key learning

TOYOTA/LEXUS:

• TN004 - Key Programming
• TN005 - Advanced diagnostic functionality. Key programming (Immo Box - mechanical keys - requires ZN039-2)
• TN006 - Advanced key programming by diagnostics (Smart Key programming - requires ZN039-2)
• TN007 - Advanced diagnostic functionality and key programming (Smart Keys programming for models up to 2016/2017)
• TN008 - Advanced diagnostics and key programming
• TN010 - Mileage recalibration

Tesla

• TS001 - Key Learning Models S/X
• TS002 - Bosch Airbags Read/Write EEPROM/Clear Crash

Volvo

• VL003 - Instrument Cluster Data Manager
• VL004 - HITAG 2 Key Learning and Central Car Configuration

Peugeot/Citroen (PSA):

• BSI Functions: Service interval reset, Clear faults log, Verify/set PIN, Virginize
• Change ID in BSI, Telematics, Airbag, MDS
• Clear crash data in some Airbag modules by dump

VAG

• AN002 - Cluster CAN - Calibration
• AN003 - Cluster PIN-CAN - Calibration
• AN004 - Immo panel - Read PIN
• AN005 - Immo panel EDC16 - Read PIN\&CS
• AN006 - Cluster K-Line - Calibration
• AN007 - ECU ConfData - Read ECU EEPROM
• AN008 - Flash Counters
• AN010 - Airbag ConfData - Airbag reset
• AN011 - TV Configuration - TV in motion
• AN012 - EDC16 calibration - mileage in ECU
• AN014 - EDC17 PIN - Read Immo Data PIN\&CS from ECU
• AN015 - Flash Memory ECU - by OBD
• AN018 - Dealer key learning Q7- spare key (2006 - 2008)
• AN019 - Prepare Dealer Key Q7 - spare key (2006 - 2008)
• AN021 - ME7 ConfData - read and write ECU EEPROM all by OBD
• AN023 - VW Crafter - Read/Write ECU ConfData, Key learning, ECU and Immobilizer Diagnotics, Remote Control Diagnostic, ECU ConfData in Direct Mode, ECU Adaptation (Autodetect/Manually enter ECU PIN/CS)
• AN024 - Key learning for EDC16 models - If PIN and CS are known
• AN025 - EDC16/MED9/Simos PIN/CS - Read Immo Data
• AN026 - Dealer key learning
• AN027 - Q7 2008+
• AN028 - Cluster CAN UDS
• AN029 - IMMO Data Immobiliser/ECU
• AN030 - Key Adaptation (All VAG Models)
• AN031 - Dealer Key Preparation - Models up to 2012
• AN032 - Security code by CAN
• AN033 - ECU ConfData (EDC15, ME7.x.x) - Read ECU EEPROM by OBD
• AN034 - Cluster - PIN/Calibration - K-Line - Mileage for all Models up to MY 2006
• AN036 - Airbag (K-Line/CAN) - Airbag reset for models up to MY 2008
• VN003 VAG key learning special function
• VN012 - Security data extraction for VAG vehicles with Magneti Marelli 9GV ECU
• VN013 - ECU authorization for all Immo 3 and Immo 4 vehicles
• VN015 - Odometer recalibration for VAG vehicles
• VN018 - Advanced diagnostics for VAG vehicles

MCLAREN:

• Complete vehicle scan
• Read and clear Diagnostic Trouble Codes (DTCs)
• Unit information display
• Live data monitoring

Other Functionalities Already Included in AVDI Base for VAG:

• Diagnostic channel adaptations
• Key programming by channel if the PIN is known (done in diagnostics in Instrument Cluster) - Guided functions for ECU, Instrument cluster, Navigation, Steering wheel, Electronic parking brake, Telephone, Comfort module and Body Control Module (enable/disable)
• Enable video in motion for MMI 2G and 3G
• Steering lock adaptation (done in diagnostics on a separate channel)
• 7-digit to 4-digit PIN conversion
• DPF remove by DUMP - EDC16 (checksum needed), EDC17
• Key Programming, Mileage Calibration and module replacement for all VAG Immo III and III+ vehicles
