Sargent - 8272 - 12V Electrified Mortise Lock - Double Cylinder - F...
Description
Description
Sargent - 8272 - 12V Electrified Mortise Lock - Double Cylinder - Fail-Safe - LFIC Prep Less Core - Rose Trim Function - Grade 1
8272 Series Electrified Lever Mortise Locks designed and constructed with high quality components to provide maximum security. The Sargent electrified 8272 series locks represent over a century of innovation and experience in manufacturing hardware and are the industry's benchmark for mortise locks: Strong - Durable - Flexible - Innovative and Secure.
Features:
- Latchbolt retracts in 1/2 of a second with applied power. Removing power allows latch to be projected back to the extended position.
- No heating detectable with extended latch holdback.
- Field reversible for handing.
- Can be used in conjunction with any access control application using standard mortise locks.
- Creates a push/pull operation that satisfies both in-swing and out-swing doors.
- Access controlled via an access control system or by physical key override.
- Environmentally friendly with low power requirements.
- Motorized latch retraction and spring back extension provides quiet operation.
- Smooth latch retraction with applied pressure of over 50lbs to the door.
- Provided with Electrolynx connectors for ease of installation.
Product Specifications:
| Manufacturer | Sargent |
| Grade | Grade 1 |
| Application | Complete Lock |
| BAA Qualified | Yes |
| Fire Rated | 2 Hours {B} |
Technical Specifications:
| Function | 72-Electrical Fail Safe |
| Cylinder Type | LFIC Prep Less Core |
| Number of Pins | 6 |
| Key(s) | Cut |
| Number of Keys | 2 |
| Hand | Field Reversible |
| Door Thickness | 1-3/4" |
| Bolt Projection | 3/4" |
| Strike Type | ASA |
| Strike Height | 4-7/8" |
| Strike Width | 1-1/4" |
| Screws | Combination |
| Power | Hard Wired |
| Amp Draw | 500mA Peak, 15mA Holding |
| Product Type | Electric Mortise Lock |
