Description
Description
Camden CX-ED1579L-BK Low Profile Mortise All In One Electric Strike for Fire Rated - 5 Black Faceplates - Grade 1
Grade 1 'All In One' fire rated strike, 12/24V AC/DC, for mortise and cylindrical locksets, comes with 5 black faceplates
Features:
- For mortise and cylindrical locksets
- 3/4" (19mm) latch projection (throw)
- 5 stainless steel faceplates included
- Selectable fail safe/fail secure operation
- Selectable 12/24V AC/DC
- Latch monitoring
- Non-Handed, LH/RH
- Easy Fit connectors for power and monitoring wires
- Stainless steel strike body
- 5 year warranty
Specifications:
| Voltage | 12/24V AC/DC |
| Current Draw | 260 mA @ 12V AC/DC 150 mA @ 24V AC/DC |
| Static Strength | 1,500 Lbs. |
| Dynamic Strength | 70 Ft-Lbs. |
| Mode | Fail-Safe/Fail-Secure, Field Selectable |
| Operation | AC - Buzz DC - Silent |
| Duty | Continuous (DC) |
| Mounting | Non-Handed |
| Endurance | 1,500,000 Cycles (Factory Tested) 250,000 Cycles (Ul Verified) |
| Fire Rating | UL10C/Can4-S104 3 hour (fail secure only) |
| Latch Bolt Monitor | SPDT, 100 mA @ 24 VDC |
| Dimensions | 3.25"L x 10.65"W x 2.13"H |
