BEA - 10SPARROW - Sparrow Industrial Motion Sensor with Flexible Mounting - 12 to 24V AC/DC
The Sparrow is designed to operate in industrial or harsh environments. It is ideal for motion detection, vehicle-flow management, security or worker automation applications in Industrial settings. Additionally, the Sparrow can be used to detect any movement at the base of escalators, moving sidewalks or similar conveyor systems.
Features:
- Flexible MountingMounting height from 6 1/2 feet to 20 feet
- Adjustable for Optimal Detection Ten sensor-sensitivity settings can be applied to optimize detection.
- Weather Resistant IP64-rated enclosure for industrial and harsh environments.
- Customizable Settings Immunity settings can be adjusted to reduce unwanted detections caused by rain, snow, and header vibrations.
Specifications:
| Model No | 10SPARROW |
| Technology | Microwave Doppler radar Transmitter Frequency (24.150 GHz) Transmitter Radiated Power ( <20 dBm EIRP) Radiated Power Density ( <5m W / cm²) |
| Detection Mode | Motion |
| Tilt Angles | -90 - 30° in elevation -120 - 120° latera |
| Output | Relay (free of potential change-over contact) Max. Contact Voltage (42 VAC/VDC) Max. Contact Current (1 A resistive) Max. Switching Power (30 W DC; 60 VA AC) |
| Minimum Detection Speed | 2 in/s (measured in the sensor axis) |
| Mains Frequency | 50 - 60 Hz |
| Supply Voltage | 12 - 24 VAC; ±10% 12 - 24 VDC; 30% / -10% |
| Power Consumption | <2 W |
| Mounting Height | 6 1/2 - 20' |
| Dimensions | 5 1/2" (L) x 2 1/4" (H) x 2 1/5" (W) |
| Materials | ABS |
| Temperature Range | -22 - 140°F |
| Degree of Protection | IP64 |
| Norm Conformity | EMC: 2004 / 108 / EC, R and TTE: 1999 / 5 / EC |
