Autel MaxiSys Auto Diagnostic Tool Code Reader OBD2 Scanner ECU Coding MS906BT


- Extraordinarily powerful Samsung Exynos Hexa-core processor

- 8.0” 1024x768 LED-backlit glossy Multi-Touch capacitive display with IPS technology for ultra-mobility

- Internal reliable 32GB SSD for better performance

- Built-in 8-megapixel rear camera with autofocus and flashlight

- 802.11b/g/n Wi-Fi to access your favorite web resources

- Unique ergonomic design with rubberized outer protection and a rugged internal housing

- Built-in rechargeable lithium-polymer battery for up to 14 hours of continuous operation

- USB, audio and auxiliary ports make it easy to connect accessories

- Open source Android Operating System for fast boot-up and multitasking

- Easy and intuitive navigation makes finding what you need simple and fast

- The most extensive complete system coverage for more than 80 US, Asian and European makes and models

- Exceptional OE-Level functionality from comprehensive OBDII diagnostics & services to advanced ECU coding

- Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, coding etc.

- Smart AutoVIN technology for identifying vehicle easily

- Automatic system and software updates with real-time push message notifications via internet

- Cloud-based MaxiFix online community provides a vast database of diagnostic and repair tips and proven filed fixes

- One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized

- Enhanced wireless BT connectivity between the display tablet and VCI device allows greater mobility and ease at work

- Convenient data management system for managing internal program applications and reviewing data


Operating System: Android™ 4.4.2, KitKat

Processor: Samsung Exynos T5260 6-Core Processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15)

Memory: 2 GB RAM & 32 GB ROM

Display: 8.0" LED capacitive touch screen with 1024x768P resolution

Connectivity: Wi-Fi (802.11 b/g/n), USB: 2.0, Mini USB 2.0, Wireless BT V2.1+EDR, Class1, HDMI 1.4a, SD Card (support up to 32 GB)

Camera: (rear) Rear-facing, 8.0 Megapixel, AF with Flashlight

Sensors: Gravity Accelerometer, Ambient Light Sensor (ALS)

Audio: Input/Output Microphone, Single Speaker, 3-Band 3.5 mm stereo/standard headset jack

Power: and Battery 10,000 mAh 3.7 V lithium-polymer battery, Charging via 12 V AC/DC power supply

Input Voltage: 12 V (9-35 V)

Power Consumption: 5 W

Operating Temperature: -10 to 55°C (14 to 131°F)

Storage Temperature: -20 to 70°C (-4 to 158°F)

Dimensions: (W x H x D) 270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”)

Weight NW: 1.05 kg (2.3lb.)


MaxiSys MS906 TS & BT User Manual V2.0 EN190613.pdf
