Cal-Royal - EJHIL Series Digital Single Locking Interconnected Touchscreen Door Lock - Pin Code / RFID - Grade 2
Features:
- 4-6 Digit Code Combination
- 500 Rfid Card/Keyfob Per Lock
- Proximity Rfid Card (13.56 Mhz)
- Rfid Keyfob (Optional)
- Master Code
- 500 User Codes Per Lock
- 2 One Time User Codes
- Passage Mode
- Weather Resistant
- 9v Battery Emergency Port
- Anti-Tamper Lock-Out
- Lock-Out Mode
- Non-Handed, Reversible
- Low Battery Indicator
- Touch Screen To Wake Up Or Lock Door
- 2 Year Warranty
Specifications:
| Applications | For offices, apartments, condo units, residential, commercial, and public buildings |
| Door Ranges | 1 3/8" to 1 3/4" standard |
| Deadbolt | 1" throw, UL-listed adjustable 2 3/4" or 2 3/8" brass with hardened steel pin. Standard 2 1/4" x 1" face plate, packed with 1/8" plastic filler for 1 3/8" door preparations. |
| Latch Bolt | 1/2" throw, UL-listed 2 3/4" standard backset |
| Latch Faceplate | Standard 2 1/4" x 1" face plate, packed with 1/8" plastic filler for 1 3/8" door preparations |
| Strikes | T-strike standard, 2 3/4" x 1 1/8" square corner deadbolt strike. Packed with (2 pcs) 3" screws and wood frame reinforcer. |
| ANSI Standards | Meets ANSI / BHMA A156.12 Series 5000, Grade 2 requirements |
| Proximity RFID Card (Standard) | 2 pcs included. Compatible with existing MIFARE infrastructures. Operates at 13.56 MHz in accordance with ISO 14443. Inductive distance up to 1 3/16". |
| RFID Keyfob (Optional) | Dual frequency enamel fobs (125 kHz + 13.56 MHz). Size: 1 1/8" x 2". Comes with metal keyring. |
| Power Supply | 4 AA 1.5V alkaline batteries (included) |
| Weather Resistant | Operates in temperatures from -30°F to 150°F (-35°C to 66°C) at 85% relative humidity. |
| Touch Screen | Responds to human touch for convenient entry or programming access. Automatically returns to sleep mode after operation. |
Includes:
- UL-Listed Adjustable 2 3/4" or 2 3/8" deadbolt, 2 1/4" x 1" faceplate with plastic filler
- UL-Listed 2 3/4" backset, 2 1/4" x 1" faceplate with plastic filler
- 2 RFID Cards, 4 Batteries
- T-Strike, 2 3/4" x 1 1/8" Deadbolt Strike
- 3" screws with wood frame reinforcer
