Global Door Controls - DC-70BC - Heavy Duty Door Closer with Adjustable Spring - Sizes 1-6 - Grade 1

Global Door Controls - DC-70BC - Heavy Duty Door Closer with Adjustable Spring - Sizes 1-6 - Grade 1

Closer - Closers shall be TA model number DC70, full rack and pinion type with cast aluminum body. All closers shall be provided with non-critical hex-key adjustment to independently regulate the sweep, latch and back check. Closers shall be non-handed with full cover and projection of 2-1/2" from the surface of the door. Closer shall have full spring adjustment from size 2 to size 6. The closer shall be pre-adjusted at the factory to size 3 for DC70. Each closer shall be adjusted for each door condition and mounted to allow the maximum degree of swing.

Features:

• ANSI A156.4 Grade 1 UL10C and UBC 7.2 for positive pressure
• ANSI A117.1 and ADA for barrier-free accessibilily
• Tri-Pack with regular, parallel and top-jamb mounting, instructions and full size template
• Standard spring adjustment from size 2 to 6
• Non handed
• Standard with adjustable sweep, latch and back check
• Full plastic cover
• SRT - Self Reaming and Tapping Screws
• Standard hole pattern and mounting location
• Finish: AL- Aluminum, Black

Options:

• DA - Delay Closing Action
• HO - Friction Hold-Open Non-Handed Arm
• CUSH - Heavy Duty Parallel Mount Cush Arm
• HO-CUSH - Heavy Duty Parallel, Hold-Open Cush
• Arm 70-09 - Drop Plate, Pull-side Mount
• 70-11 - Back Plate - Top Jamb Mount Plate
