ABRITES - KT011 - Key Inspector

ABRITES - KT011 - Key Inspector

KT011 - Key Inspector is an additional software function that allows you to read all the data from a key. It works together with the Abrites PROTAG Programmer. Once you place the key in the PROTAG programmer and read it using Key Inspector, you will see all the information contained inside the key.

Features:

• Key type
• Vehicle Identification Number (VIN)
• Vehicle colour code
• Vehicle Type
• Time and date of last drive
• Battery voltage
• Quantity of fuel in the tank
• Mileage stored in the key
• ALL POSSIBLE INFORMATION CONTAINED IN THE KEY

PIT (PCF 7931, 7935, ELMOS):

BMW Keys

• Key make - BMW
• Remore control functionality available - YES or NO
• Type of transponder / processor (7935 or 7931) / (ELMOS)
• Position of the key in the immobilizer - "from 0 to 9"
• Fixed code of the key: "16 characters"
• Vehicle equipment data
• VIN number
• Mileage values stored in the key upon last start

HITAG2:

• All vehicles
  • Transponder ID: xx xx xx xx
  • Transponder type - PCF 7936, 7945, 7941, 7961, etc.
  • Transponder status - Locked (already programmed) or Blank (not programmed)
• OPEL/VAUXHALL
  • Key make: OPEL/VAUXHALL
  • VIN number
  • Mileage values stored in the key upon last start
• RENAULT
  • VIN number
  • Registration plate (if provided)
  • Mileage values stored in the key upon last start
  • Fuel level (litres)
  • Oil level (proportion)
  • Date of return
  • Date of the technical inspection (if provided)
• Owner data:
  • Company
  • First name
  • Name
  • or Tel. Mobile
  • or Tel. Fix
  • City
  • Address
• BMW:
  • Key make - BMW
  • Remote control functionality available / Hands-free
  • VIN number
  • Vehicle colour code
  • Interior upholstery (UPH code)
  • Key blade cutting code
  • Frequency of the remote control
  • Position of the key in the immobilizer - "from 0 to 9"
  • Date of first registration of the vehicle
  • Mileage values stored in the key upon last start
  • Date / time of the last use of the key
  • Fixed code of the key: "16 characters"
  • Fuel level (litres)
  • Battery voltage
  • Outside temperature
  • Coolant temperature
• Example:

  • Hitag 2 key type
  • Key Identifier: B5 B1 7D 97
  • Micro controller inside key is PCF 7945.
  • The transponder is NOT blank
  • This key is from BMW vehicle
  • Key is WITH remote control.
  • VIN: WMWZC51000WK70320
  • Colour code of the vehicle: 0A48
  • UPH code of the vehicle: FSGZ
  • Key blade cutting code: 4B7490
  • Key remote control frequency 868 MHz
  • Key is programmed in position: 1
  • First registration of the vehicle: 15/12/2010
  • Odometer value while last usage of the key: 165247
  • Last time when this key is used: 21/02/2019 18:11
  • Fuel in the tank (litres): 0
  • Battery voltage: 14.970
  • Outside temperature: 17.50
  • Coolant temperature: 68

SOKYMAT 8E:

• Transponder ID

MEGAMOS48 (ID48):

• Transponder ID
• Transponder status - Locked (already programmed) or Blank (not programmed)

Temic11:

• Transponder ID

Temic12:

• Transponder ID

MEGAMOS 13:

• Transponder ID

TEMIC 8C:

• Transponder ID

HITAGPro:

• PORSCHE keys:
  • VIN number: xxxxxxxxxxxxxxxx
• BMW keys:
  • Date of first registration of the vehicle
  • Chassis type
  • Current VIN
  • Vehicle colour code
  • Interior upholstery (UPH code)
  • Mileage values stored in the key upon last start
  • Date / time of the last use of the key
  • Fuel level (litres)
  • Battery voltage
  • Outside temperature
  • Coolant temperature
  • Position of the key in the immobilizer - "from 0 to 9"
  • Key blade cutting code
  • Date of creation of the key
  • Initial VIN
  • Remote control code
• BMW G-Series keys:

  • VIN (current/initial)
  • Odometer
  • Last drive
  • Fuel
  • Battery voltage
  • Shipping
  • Temperature (coolant/outside)
  • Color code
  • Upholstery code
  • Remote frequency
  • Display key/ no display

HITAG AES:

• Transponder ID
• Transponder type
• RENAULT
  • VIN number
  • Registration plate (if provided)
  • Mileage values stored in the key upon last start
  • Fuel level (litres)
  • Oil level (proportion)
  • Date of the technical inspection (if provided)
• RENAULT
  • Company
  • First name
  • Mileage values stored in the key upon last start
  • Fuel level (litres)
  • Oil level (proportion)
  • Date of the technical inspection (if provided)

HITAG3:

• Transponder ID

MEGAMOS AES (ID88):

• Transponder ID
• Position of the key in the immobilizer
• Transponder status - Locked (already programmed) or Blank (not programmed)
• Mileage values stored in the key upon last start
• The last 8 records of mileage (KM + Date)

DST AES (Tiris AES):

• Transponder ID

DST Plus (DST80):

• Transponder ID
• Transponder status - Locked (already programmed) or Blank (not programmed)

4D (DST40):

• Transponder ID

4C:

• Transponder ID

IR Key (Mercedes):

• Key type (FBS3/FBS4)
• SSID - identifier
• Position of the key in the immobilizer
• Key usage counter
• Functional type
• Firmware version
• Sub-data
• Operational status
• Hands-free
• User data 1

ID Badges:

• ID card
• Type card

Keyless DST-AES Keys for BMW Bikes:

• Production date
• Place of production (factory number)
• VIN of key

Audi A6/A7/A8 BCM2 keys (keyless):

• Odometer
• Hardware/software version
• Key date of production

Depending on the type of key, the information shown can be full or partial. KT011 is extremely useful for insurance agencies, law enforcement and independent service shops, but can also be used by locksmiths.

An active AMS and PROTAG are required in order to be able to use KT011 - Key Inspector.
