Medeco - 11C601 - Commercial Maxum Deadbolt - 6-Pin Single Cylinder - 2 3/8 Inch Backset with 1 1/8 Inch Front - 44 Keyway - 628 Side Pin - Grade 1

Medeco - 11C601 - Commercial Maxum Deadbolt - 6-Pin Single Cylinder - 2 3/8" Backset with 1 1/8" Front - 44 Keyway - 628 Side Pin - Grade 1

The Medeco 4 high security Maxum deadbolt uses hardened steel inserts and rotating pins to provide drill and pick resistance in accordance with UL437 standard for safety for key locks.

The most robust deadbolt available, the Maxum can withstand physical attacks such as kicking-in and prying. The patented M4 key system also makes unauthorized key duplication virtually impossible. Battering rams, crowbars, drills, and saws have proven to be no match for the Medeco 4 Maxum Deadbolt. The Maxum Deadbolt has been recognized numerous times by Consumer Reports as the "Best Door Lock" available.

Features:

• Medeco 4 cylinders meet or exceed ANSI/BHMA A156.30 and 156.5 Grade 1 high security criteria, which includes testing for strength, durability, and resistance to surreptitious entry along with patented key control.
• Medeco 4's cylinder design includes 4 Side Pins made up of 3 Finger Pins and 1 Lift Pin. The Lift Pin is activated by contact with the movable element in the key, providing a high level of pick resistance.
• Patented key control provides protection against the unauthorized duplication of keys.
• UL 437 listing provides assurance that cylinders meet universal standards for endurance, drill and pick resistance, and resistance against other types of forced attack.
• Patented movable element in the key deters unauthorized 3D printed copies of keys or blanks.
• Angled cuts on the keys, along with rotating pins, provide added dimensions that dramatically increase key combinations. Secondary side pin bitings provide even greater combinations, making very large systems possible.
• Cylinder side pins and a lift pin which engage the sidebar prevent the key from turning until the elements are aligned in the correct position, protecting against bumping and picking.
• If you are able to cut Biaxial or Medeco 3 keys, you are able to cut Medeco 4 keys on the same equipment.
• Finger Pins work with Secondary Side cuts on the key to provide increased security and greater potential combinations.
• Solid brass collar spins under pressure to prevent wrench attacks.
• Steel shroud over bolt protects against “ice pick” type attacks.
• High box design security strike plate with 2 inch screws anchor the strike directly to the structure behind the frame, preventing “kick-in” attacks.
• Solid 1'' hardened steel bolt in heavy gauge steel housing provides maximum defense against physical attack.
• Fits doors 1 3/8’’ to 2 1/2’’ thick
• Standard 2 1/8’’ crossbore and 1’’ edge bore (ANSI A115.13 prep)
• Designed to accommodate both mortise and drive-in face applications for greater flexibility and ease of installation.
• UL Listed for use on fire doors.
• The Maxum Deadbolt comes in a commercial and residential version. The difference between the commercial and residential deadbolt is that the residential version has a trim piece that’s more aesthetically suited for homes.

Benefits:

• Maximum physical protection from attacks
• Drill Protection: Offers maximum protection against drilling attack with solid-brass construction and strategically placed steel inserts.
• Large retrofit capability: Available in retrofit cylinder formats to fit most popular manufacturer door hardware.
• Restricted Keys: Utility patented keys are only available through authorized dealers and require a special key cutting machine and access to Medeco specific blanks.
• System Flexibility: Medeco 4 integrates with M4 BiLevel for custom security level at each opening.
• Master keying Capabilities: Secondary side pin bitings provide expanded master keying capabilities. Very large systems are possible.
• Highest Quality: Medeco's Maxum Deadbolt is Grade 1 certified for strength and durability.
• Maximum Resistance: Solid brass design is secured with high-tensile steel mounting bolts for maximum resistance against hammer and prying attacks.
• Stands Up: Maxum's bolt is made of hardened steel and is virtually impossible to saw through with a hacksaw.
• Captive thumbturn feature: Converts the inside cylinder of a double cylinder to a thumbturn for easy exit while the facility is occupied. Easily remove the thumbturn key to guard against unauthorized entry.
• Security features protect against drill, wrench, ice pick, kick-in, hammer, bumping, and prying attacks.

Specifications

• Body Material: Solid brass
• Core Type: Fixed, Interchangeable
• Cross Bore: 2 1/8"
• Cylinder Format: Conventional, Small Format
• Cylinder Pins: 5 pin, 6 pin
• Cylinder Type: Component
• Deadbolt Type: Bored
• Device Type: Mechanical
• Edge Bore: 1"
• Grade: 1
• Key System: Mechanical
• Latch Type: Deadlocking
• Latchbolt Throw: 1"
• Latchbolt Type: Deadbolt
• Lock Type: Deadbolt
• Maximum Backset Depth: 2 3/4"
• Minimum Backset Depth: 2 3/8"
• Maximum Door Thickness: 2 1/2"
• Minimum Door Thickness: 1 3/8"
• Number of Keys: 2
• Patented: Yes
• Security Type: High Security [UL 437], Patented
• UL Listed: Yes
• ULC Listed: Yes
• Weather Resistance: Indoor/Outdoor

Applications:

• Office buildings
• Hospitals
• Schools
• Apartments and residences
• Retail outlets

Certifications:

• UL437 Listed
• UL-cUL Listed for use on fire doors having a rating up to and including 3-hours
• ANSI/BHMA A156.5, Grade 1
