Rosslare - AC-225-DIN - DIN Housing Expandable Networked Access Control for PCBA Only - 2 Readers
Review: 5 - "A masterpiece of literature" by , written on May 4, 2006
I really enjoyed this book. It captures the essential challenge people face as they try make sense of their lives and grow to adulthood.

Rosslare - AC-225-DIN - DIN Housing Expandable Networked Access Control for PCBA Only - 2 Readers

  • Product SKU: RSL-AC-225-DIN-PCBA
$468.53
Save $304.54 Was $773.07
  • Order within

    and choose FedEx 2Day® Shipping


Rosslare - AC-225-DIN - DIN Housing Expandable Networked Access Control for PCBA Only - 2 Readers

Features:
  • DIN Housing for DIN Rail Mounting.
  • Supports up to 30,000 users in off-line mode, unlimited server based capacity.
  • 20,000 event history entries per computer.
  • multi-user authentication for high-level security.
  • supports a wide range of Wiegand and PIN formats.
Specifications:
Type Network Control Panel / DIN Housing
Readers 2 reader ports, 4 reader
Output voltage: 12 VDC
Max. current: 245 mA
LED control output and Tamper Input
Inputs 4 supervised high impedance inputs. 8 or 12 supervised inputs when using MD-D02B or MD-IO84B expansion boards. Maximum voltage: 5 VDC
Outputs 4 Form C 5 Amp relay outputs. 8 outputs when using MD-D02B or MD-IO84B expansion boards
Interface RS-485
TCP / IP Molex and Terminal Block
Serial Ports 10/100 Ethernet Port
Networking Rosslare's AxTraxNGâ„¢ Server
Users 30,000 active credentials (Card & PIN)
Event Log 20,000 Events
Housing Protective Cover & DIN Rail / Wall Mount
Standard Approvals CE - Safety, ENC, RFI, LVD RED 2104/53/EU; FCC - CFR47 Part 15b
Dimensions 7.6 x 5.4 x 1.5 in.
Enclosure Protective cover, with 1 expansion slot for MD expansions
Operating Temperature 0°C to 49°C (32°F to 120°F)
Weight 0.36 kg (12.7 oz)
