Schlage - L9092EUP - Fail Secure Electric Mortise Lock with 1-1/4 S...
Description
Description
Schlage - L9092EUP - Fail Secure Electric Mortise Lock with 1-1/4" Strike Width and C Keyway - 03 Lever - Grade 1 - 626 (Satin Chromium Plated Finish)
The Schlage L Series has long been the benchmark for mortise locks. Beyond strength and security – it offers tremendous flexibility to allow it to meet the needs of most every application
Product Specifications:
| Vendor | Allegion |
| Manufacturer | Schlage |
| SKU | L9092EUP 03A 626 |
| UID | SCH100L9092EUP03A626 |
| Grade | Grade 1 |
| Installation | Commercial |
| Unit of Measure | Each |
| Base Material | Brass or Bronze |
| Fire Rated | 3 Hours {A} |
| ADA Compliance | Yes |
Technical Specifications:
| Function | 9092EU-Fail Secure |
| Lever/Knob Design | 03 Lever |
| Rose/Escutcheon Design | A Rose |
| Cylinder Type | Conventional Cylinder |
| Num Pins | 6 |
| Keyway | C |
| Keying | Keyed Different |
| Key(s) | Included |
| Number of Keys | 2 |
| Hand | Field Reversible |
| Door Thickness | 1-3/4" |
| Bolt Projection | 3/4" |
| Strike Number | 10-072 |
| Strike Type | ASA |
| Strike Height | 4-7/8" |
| Strike Width | 1-1/4" |
| Dust Box | Plastic |
| Screws | Combination |
| Power | Hard Wired |
| Operating Voltage | 12VDC/24VDC |
| Amp Draw | 400mA |
| Product Type | Electric Mortise Lock |
