Abrites VAG Full Software Diagnostics Package (VN002-VN003-VN005-VN006-VN007-VN009-VN012-VN013-VN015) for Audi, VW, Seat, Skoda, Bentley

Available: In Stock
  • Product SKU: VAG FULL
$185.00
  • Order within

Abrites VAG Full Software Diagnostics Package (VN002-VN003-VN005-VN006-VN007-VN009-VN012-VN013-VN015) for Audi, VW, Seat, Skoda, Bentley

Included:

- VN002 - Special function for adapting electronic modules for VAG vehicles
For owners of functions AN043, AN045, AN046, AN048, AN049, AN052, AN053, AN055, AN056, AN057 please click here to see the pricing for completion

Extracting and displaying immobilizer related data by diagnostic. Ability for alignment of immobilizer related data - cluster/ecu. Displaying immobilizer related data from dump of flash and eeprom of micronas mcu in IPC.
Read/Program memory of instrument cluster immobilizer
Read/Update immobilizer related data
Read/Update immobilizer data in VDO dashboards with NEC microcontroller (2009+) by OBDII
Extracting and displaying PIN code, control module configuration memory content, component security data from engine control units EDC16, MED9.x, Simos PPD 1.1/1.5, Magneti Marelli 4HV,7GV. Emergency start for engine control units EDC16. The whole EEPROM could be read for EDC15/ME7/EDC16. For MED9 and Simos engine control units only the PIN/CS/MAC is displayed.
Advanced Diagnostic Functionality - Ability to manage stored crash data and configuration memory of electronic control unit. Read/Update Config Data of airbag control units Siemens (CAN bus - ISO15765). Audi A6/Q7/Allroad, VW Golf5..., Skoda Octavia II ..., Seat Altea ... With this special function, you can Read/Update ConfData memory of the airbag module. Clear the crash data of the airbag module.
Covered units for Read/Update ConfData:
1. All Siemens CAN Airbags 2003-2008 like 4F0959655B (Audi A6/Q7/Allroad 2003-2008),
1K0909605AB, 1K0909605C, 1K0909605AD, etc...
2. K-Line Airbags (Siemens and Bosch) - 1C0 909 605 C, 8L0 959 655 A, 1J0 909 609, 6Q0 909
605 C,6Q0 909 605 A, 6Q0 909 605 B, 3B0 959 655 B, 1C0 909 605 F, 1C0 909 605 H, 1J0 909
607, 1J0 909 603, 4B0 959 655 C, 4B0 959 655 J, 4D0 959 655 C, 8L0 959 655 F,8A0 959 655
C, 8A0 959 655 K, 8A0 959 655 K, 4D0 959 655 H, 8D0 959 655 C, 8D0 959 655 L
Preparation of a key ready for adaptation by diagnostic to the vehicles with BCM2 - Audi A4, S4, RS4, A5, S5, RS5, A6, A7, A8, Q5 / VW Touareg
+ ILM Front passenger ((ILM Beifahrer) - Audi A8 2003-2010
Component protection generation 2
EZS-Kessy Audi A6/Q7 2004-2009 by OBDII
Comfort module Audi A6/Q7 2004-2009 by OBDII
Climantronic Audi A6/Q7 2004-2009 by OBDII
Airbag Audi A6/Q7 2004-2009 by OBDII
Airbag Audi A4/A5/Q5 2008+ from Bosch by OBDII
Instrument cluster Audi A6/Q7 2004-2009 by OBDII
Instrument Cluster Audi A4/A5/Q5 2008+ by OBDII
Infotainment electr. Audi A4/A5/Q5 2008+ by OBDII
- All other modules (e.g. DSP) with component protection generation 2
for A6/Q7 2004-2009 and A4/A5/A5 possible only if you have dump from gateway from where module was originally build
+ Adaptation of engine control units to the vehicle - EDC16,EDC17, MED17, MED9, Simos PPD, ME7.5.20, ME7.5.30
Kessy Audi A8/VW Touareg/Phaeton
Comfort module VW Passat B6/CC
Transmission gearbox Audi A6/Q7/Allroad/A8
EZS-Kessy Audi A6/Q7/Allroad
BCM2 immobilzier - Audi A4, S4, RS4, A5,S5, RS5, A6, A7, A8, Q5 / VW Touareg
+read the PIN and CS of the EDC17/MED17 engine control units. With this function is possible to read even engine control units 2012+ which are with
updated software and is not possible to read normally by OBDII.With this special function the EDC17/MED17 is not read through OBDII - you should have direct connection to the engine
control unit. It is possible to make this on the table, you need to connect only 12V, GND, Ignition, CAN-H and CAN-L. It is possible to read the ECU also in the car, but you need to find
somewhere the CAN-H (orange-black) and CAN-L (orange-brown) wires. So connect them to the AVDI and you will be able to read the engine control units.
+ adapt the transmission control unit (TCU) to the immobilizer (BCM2). For that purpose is necessary first to read the TCU. The TCU is not possible to be read by OBDII,
but is possible to read it when you connect the TCU on the table, or when you connect the AVDI to the internal CAN-Bus of the car.
To read from the internal CAN-Bus, find the orange/black and orange/brown CAN wires and make the following connection of the AVDI:
- orange/black <-> CAN-H (PIN6 of the OBDII)
- orange/brown <-> CAN-L (PIN14 of the OBDII)
- Ground <-> GND (PIN4 of the OBDII)
- 12V <-> 12V (PIN16 of the OBDII)
+reading the PIN/CS/MAC of the Simos PCR 2.1 engine control unit.
NOTE: This function requires internet access New AVDI Interface or active AMS is required to purchase this special function.

VN003 - Special function for learning keys to VAG vehicles

For owners of functions AN043, AN044, AN045, AN049, AN050, AN059 please click here to see the pricing for completion

 +Extracting and displaying immobilizer related data by diagnostic. Ability for alignment of immobilizer related data - cluster/ecu. Displaying immobilizer related data from dump of flash and eeprom of micronas mcu in IPC
Read/Program memory of instrument cluster immobilizer
Read/Update immobilizer related data
Read/Update immobilizer data in VDO dashboards with NEC microcontroller (2009+) by OBDII
+ Extracting and displaying PIN code, control module configuration memory content, component security data from engine control units EDC16, MED9.x, Simos PPD 1.1/1.5, Magneti Marelli 4HV,7GV. Emergency start for engine control units EDC16. The whole EEPROM could be read for EDC15/ME7/EDC16. For MED9 and Simos engine control units only the PIN/CS/MAC is displayed.
+ This function will allow the preparation of a key ready for adaptation by diagnostic to the vehicles with BCM2 - Audi A4, S4, RS4, A5,S5, RS5, A6, A7, A8, Q5 / VW Touareg
+ Guided key adaptation functions, preparation keys suitable for the vehicle (dealer's keys). Included are also Audi A6, Audi Q7, Audi Allroad, VW Crafter(with EDC16 ECU), VW Passat, (BCM2 based vehicles are supported only with the help of ABProg*)
Key programming/adaptation
Reading security code (PIN) and component protection by OBDII - VW CRAFTER
EZS - Kessy (Q7/A6/Allroad) - With this function you can prepare dealer key/learn dealer key- Read/Update ConfData from EZS - Kessy (Q7/A6/Allroad)
Programming keys by OBDII (VAG with 16 bytes Component Security) - VW Crafter, Audi R8, VW Golf 6, VW Multivan 2009+, VW EOS 2009+, VW Caddy 2009+, VW Scirocco, VW Polo 2009+, VW Bora 2010+, VW Jetta 2010+, Skoda Octavia II 2009+, Skoda Superb 2009+, Skoda Fabia 2009+, Skoda Yeti 2009+, Seat Leon 2009+, Seat Altea 2009+, Seat Exeo 2009+, Seat Ibiza 2009+, ...
Extracting of the 7th byte Component Security from a working key of the car (Megamos, Hitag2)
LAMBORGHINI GALLARDO
Key learning for Audi A6/A7/A8 with ALL KEYs LOST.

New AVDI Interface or active AMS is required to purchase this special function.

- VN005 - The function allows to replace immo-related parts in another vehicle, even when the brand is different or the power class is different.
The function works for the transmissions of Audi A6 2003-2010, Audi Q7 2005-2015, Audi A8 2003-2010, and for all Immo III/IV engine control units where writing is not permitted. (EDC16/EDC17/ME7/MED9/MED17/Simos benzin/Simos PPD/Simos PCR/Magneti Marelli/Delphi). The function requires internet connection and a complete VN002.

Attention:

The VN005 special function requires VN002 as well as an additional cable set (ZN052) that allows you to start and complete the operation. Each module that is adapted (TCU or ECU) will require an EM003 emulator to be built inside the car.

- VN006 - The function allows the programming of keys to ALL VEHICLES with Immo III/IV immobiliser systems and Megamos 48 transponders.

The function works both when there is a working key and in ALL KEYS LOST situations.

A ZN053 AVDI Extractor Cable IS REQUIRED when purchasing the special function.

The procedure also requires a ZN051 Distribution Box and an internet connection.

VN007Mileage recalibration for MQB vehicles.

Mileage recalibration for vehicles based on the MQB platform from 2014 onwards. For a full list of supported models.

Active AMS and internet connection are required.

- VN009  - Key programming for MQB vehicles

Key programming for vehicles based on the MQB platform. This includes all models starting from 2012 onwards.

PROTAG programmer, active AMS and internet connection are required.

VN012Security data extraction for VAG vehicles with Magneti Marelli 9GV ECU

Reading the PIN and Component Security of the Magneti Marelli 9GV ECU. Procedure is done by OBDII with a working key or on the bench (using the ZN051 Distribution Box without opening the ECU) when all keys are lost.

VN013ECU authorization for all Immo 3 and Immo 4 vehicles

Performing authorization (using the ZN051 Distribution Box) of the vehicle ECU in order to update the engine software or to start the vehicle for ALL IMMO 3/IMMO 4 ECUs (Bosch, Siemens/Continental and Magneti Marelli). Allows entering into reflashing mode to update with a SGO/FRF file or to perform an emergency start to the vehicle.

VN015 - Odometer recalibration for VAG vehicles

-Mileage recalibration for Audi A6/A7 (4G) and A8 (D4) and VW Touareg 7P produced from 2010 until 2017 BY OBDII.
The function works with UDS dashboards.
-Reading and updating internal control module configuration memory by diagnostics.
Extracting and recalibration security access codes, PIN, component security bytes, current unit mileage values by K-line, CAN bus and UDS.
-Cluster CAN - With this function you can establish a disgnostic session with the instrument cluster using KWP2000 over TP2.0 or UDS.
You can Read/Update the odometer values. Supported types are: - VDO/MM/Visteon -2007 (CAN TP2.0)- VDO with NEC μC 2009+ (CAN UDS)- JCI with NEC μC
and 95320 EEPROM (CAN UDS)- Magneti Marelli with 9S12 μC (CAN UDS)- A8(4H)/A7(4G)/A6(4G)/Touareg(7P) with 95320 EEPROM (CAN UDS)
-Cluster K-Line - With this function you can establish a disgnostic session with the Instrument cluster via K-Line
(KWP1281 or KWP2000); You can Read/update the odometer value; Read PIN code; Read/Update ConfData; Read ROM/Flash from the Instrument cluster;
Automatic removing of "DEF error" for Audi A4 instrument cluster BOSCH RB8. Supported types are:- VDO66/86, Motometer- External Immobilizer - LT,
VW GOL, VW O GOL( Kostal ), Siemens 6 PIN HC05 Immo/TMS- Audi A4 B5 with/without board computer -1997- Audi A6 -1997- Audi A8 -1999- Magneti Marelli - Shadow 1/2/3/Direct-
VW Sharan/Galaxy -2000- Audi A4 Bosch RBx/RB4/RB4 Crypto/RB8 Crypto 2004+- Golf 4 Bosch RBx- VW Phaeton/Touareg, Bentley Continental,
Porsche Cayenne- Seat Exeo Bosch RB8 Crypto 2008+- Lamborghini Gallardo -2005/2005+
-Read/Update ConfData (VAG-EDC15x, VAG-ME7.1.1, VAG-ME7.1, VAG-ME7.5, VAG-Cartronic ME7.8.)
-Extracting Security access code / PIN (EDC15, ME7.x, VAG-Cartronic ME7.8) - Extracting Component security bytes
(EDC15, ME7.x, VAG-Cartronic ME7.8)- Mileage Calibration (EDC15, EDC16)

- VAG KmSpecial functions set for VAG mileage recalibration VN007, VN015
Full set of mileage recalibration special functions for VAG.

VAG Key - Special functions set for VAG key programming VN003, VN006, VN009

Full set of key programming special functions for VAG. The following hardware IS REQUIRED in order to obtain full functionality:
- ZN002 PROTAG Programmer
- ZN051 Distribution Box
- ZN053 AVDI Extractor Cable

VAG FULL - Full VAG special functions set VN002, VN003, VN005, VN006, VN007, VN009, VN012, VN013, VN015


- ZN002 PROTAG Programmer
- ZN051 Distribution Box
- ZN052 Abrites cable set for adapting IMMO parts used together with VN005
- ZN053 AVDI Extractor Cable
