TownSteel e-Genius 7000 Series Electronic Interconnected Lock with Storeroom Function, 2-3/4" Backset and 1" x 2-1/4" Faceplate, 5-1/2" CTC, 6-pin Schlage C Keyway
The e-Genius 7000 is an interconnected lock that pairs with the AegisSecure™ management system making it a breeze with our user-friendly interface, with monitoring and analysing access activity being crucial. Our system has you covered. With support for unlimited audit trails, you can remotely retrieve detailed event logs and access history for comprehensive monitoring and analysis.
When the door is closed, the lever will not retract the deadlatch or deadbolt, ensuring instant security. For additional security with the extended deadbolt, simply lift the lever upward to engage it. To unlock the door, simply provide valid credentials and push the lever downward to re-enter with a single motion.
Features:
- Interconnected deadbolt and deadlatch
- Single motion egress
- Clutched lever design
- AegisSecure access control system
- Wireless BLE configuration from connected AegisSecure App.
- Standard multi reader technology MIFARE®, Bluetooth®, Pin Code, and 915 MHz communication capabilities.
- Networked real-time communication is available with the GW7-915 Gateway and AegisSecure System.
- Weather resistant design.
- Up to 1 year of battery life.
- Mechanical key override.
Specifications:
| Category | Feature / Parameter | Specification |
|---|---|---|
| Product Type | Product Type | Access Control (Integrated) |
| Certifications and Compliance | Certifications | ANSI/BHMA A156.12, A156.5 Grade 1 Certified, UL10C 3-hour, FCC Part 15 |
| Compliance | Meets requirements of the Americans with Disabilities Act | |
| Electronic Specifications | Users | Up to 889 (Maximum database storage capacity of lock). Varies on software database capacity. |
| Audits | Up to 2,000 (Maximum database storage capacity of lock). Varies on system audit storage capacity. | |
| Credential Verification Time | MIFARE credential: ≤ 1 second at ≤ 1/2" distance | Mobile: mobile device dependent within 20' | |
| Visual Communications | LED (red, yellow, green) | |
| Communication Standards | 2.4 GHz Wi-Fi® (IEEE 802.11b/g/n), WPA2, WPA, WEP, 802.1x, Bluetooth® low energy (version 4.2), Transport Layer Security (TLS) version 1.2, Advanced Encryption Standard (AES), 128-bit Gateway communication range Up to 100' in typical building environments. A detailed site survey is recommended for correct location and number of gateways. Reference GW7-915 Gateway data sheet for additional detail. | |
| Connectivity Options | Bluetooth via mobile device (send updates at the lock), GW7-915 Gateway (real-time communication) | |
| Battery Life | Uses 4 AA batteries; Up to 1 year | |
| Operating Temperature | Exterior: -31° to 151°F (-35° to 66°C) | Interior: 32° to 120°F (0° to 49°C) (battery) | |
| Operating Humidity | 0 - 100% | |
| Available Status Signals | Request-to-exit, Battery status, Communication status | |
| Wireless Lock Connectivity Options | 1. Mobile BLE, 2. Real-time with GW7-915 Gateway, 3. Offline RFID | |
| Reader Credential Technologies | Smart (13.56 MHz), Bluetooth Low Energy (BLE) (2.4 GHz), and Pin Codes | |
| Reader Standards | ISO 14443 | |
| Reader Maximum Read Range | Smart: up to 1/2" | Bluetooth Low Energy: up to 20' | |
| Reader Smart Credential Support | Secure sector compatibility: MIFARE Ultralight AES EV1 | |
| Reader Mobile Credential Support | AegisConnect Mobile App Bluetooth® | |
| Mechanical Specifications | Series | e-Genius |
| Latch bolt | 1/2" throw stainless steel deadlocking | |
| Escutcheon | Zinc | |
| Lever Parameters | Zinc |
