Uniview Tec NR324XP Network Recorder 32ch 16 PoE 12MP Resolution H.265 NVR
$1,14500
$1,37400
Unit price
/
Unavailable
Shipping calculated at checkout.
Secure transactionCouldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
All orders are shipped between 24 hours or less Monday through Friday from 9:00 am to 6:00pm. Orders placed after 4 p.m. EST will be shipped next business day.
Learn more
Uniview Tec NR324XP Network Recorder 32ch 16 PoE 12MP Resolution H....
From
$1,09500
$1,31400
Unit price
/
Unavailable
Description
Description
Uniview Tec NR324XP Network Recorder 32ch 16 PoE 12MP Resolution H.265 NVR
Key Features:
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- 32ch network recorder with H.265 Compression for Best-in-Class Recording and Storage Capability
- Supports 4 SATA HDD up to 10TB and has Embedded PoE Switch for all Video Channels
- Supports recording of up to 12MP Resolution Images
- Display Images up to 4K(8MP) Resolution on HDMI Output
- Concurrent Independent Displays on HDMI and VGA Monitor Outputs
- ONVIF Profile Series Compliant
- Easy Plug and Play Functionality with Automatic Device Discovery and Display
- Supports Cloud Upgrade for NVR and Cameras, with Automatic Detection of Latest Firmware and Upgrades
- Various Panoramic, Fisheye Dewarping modes are supported for live view and playback
- Features Automatic Network Recovery (ANR) Technology to enhance storage reliability when network is disconnected
- Supported by uniview tec Guard Station Client Software and Guard Viewer Mobile App's for iPhone and Android Devices
Specifications:
Video & Audio Inputs:
| IP Video Input | 32-ch |
| Audio Input | 1-ch, RCA |
Network:
| Incoming Bandwidth | 320Mbps |
| Outgoing Bandwidth | 320Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS |
| Supported Browsers | IE(IE10/11) for Windows; Firefox (version 52.0 and above) for Windows; Chrome(version 45 and above) for Windows; Edge(version 79 and above) for Windows |
Video & Audio Outputs:
| VGA Output | 1920 x 1080p / 60Hz, 1920 x 1080p / 50Hz, 1600 x 1200 / 60Hz, 1280 x 1024 / 60Hz, 1280 x 720 / 60Hz, 1024 x 768 / 60Hz |
| HDMI Output | 3840 x 2160 / 30Hz, 1920 x 1080p / 60Hz, 1920 x 1080p / 50Hz, 1600 x 1200 / 60Hz, 1280 x 1024 / 60Hz, 1280 x 720 / 60Hz, 1024 x 768 / 60Hz |
| Recording Resolution | 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF |
| Audio Output | 1-ch, RCA |
| Audio Compression | G.711A, G.711U |
| Synchronous Playback | 16-ch |
| Live view display | 1 / 4 / 6 / 8 / 9 / 16 / 25 / 36 |
| Corridor Mode Screen | 3 / 4 / 5 / 7 / 9 / 10 / 12 / 16 / 32 |
Snapshot:
| FTP/Schedule/Event Snapshot | 16-ch snapshot, up to 1080P resolution |
Decoding:
| Decoding format | Ultra 265 / H.265 / H.264 |
| Live view / Playback | 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF |
| Capability | 1 x 12MP @ 30, 2 x 4K @ 30, 5 x 4MP @ 30, 10 x 1080P @ 30, 22 x 720P @ 30, 32 x D1 |
Hard Disk Drives:
| SATA | 4 SATA Interface |
| Capacity | Up to 10TB for each HDD |
| RAID | RAID 1,5 |
Smart Features:
| VCA Detection by Camera | Face Detection, Face Comparison, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Ultra Motion Detection(UMD) |
| VCA Search | Face Search, Face Comparison Search, Behavior Search, Vehicle Search |
| People counting | People Flow Counting, Crowd Density Monitoring |
| Smart Intrusion Prevention (SIP), Face Detection, Face Comparison, Vehicle Detection, UMD, Video Metadata,Traffic Monitoring by Camera | 8-ch |
System Alarm:
| General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording / Snapshot Abnormal |
External Interface:
| Network Interface | 1 x RJ45 10M/100M/1000M self-adaptive Ethernet Interface |
| USB Interface | Front panel: 1 x USB2.0; Rear panel: 1 x USB3.0 |
| RS485 | 1 |
| Alarm In | 16-ch |
| Alarm Out | 4-ch |
PoE:
| Interface | 16 x RJ-45 10M/100M self-adaptive Ethernet Interface |
| Max Power |
Max 30W for single port Max 150W in total |
| Supported Standard | IEEE 802.3af/at |
General:
| Power Supply | 100~240V AC; Power Consumption: ≤ 15W (without HDD) |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions (W x D x H) | 400 x 363 x 74mm (15.7 x 14.3 x 2.9") |
| Weight ( without HDD ) | ≤ 4Kg (8.82lb) |
| Certifications | FCC, CE(UL - Power Supply only) |
