XTOOL - D9S - Automotive Scan Tool Topology Map Bi-Directional Control ECU Coding Full Diagnostics and 42+ Resets Support DoIP and CAN FD

XTOOL D9 is an Upgraded Version of XTOOL D8 / D8BT, It adds a topology mapping function, which can find and display the working status of all automobile systems/modules, and accurately locate automobile problems. It is always convenient for technicians to carry out maintenance and improve efficiency.

Device name D7 D8 D8BT D9 D9PRO
Support language 15 15 15 15 15
Diagnostic system Full system Full system Full system Full system Full system
Basic function 6 6 6 6 6
Special functions in the vehicle model
ECU programming and coding × × × ×
BBA online programming × × × ×
Basic coding and guidance (public) ×
Offline programming code ×
Special features 36 38 38 42 42
J2534 protocol × × × × ×
CAN FD protocol supports M811√ ×
Operating Platform Tablet Tablet Tablet Tablet Tablet
Screen Size 7 inches 8 inches 8 inches 9.7 inches 9.7 inches
Storage 1+32 (quad-core 1.6) 2+64 (quad-core 1.8) 2+64 (quad-core 1.8) 2+64 (quad-core 1.8) 2+64 (quad-core 1.8)
Connection Method line connection line connection Bluetooth line connection Bluetooth line connection line connection
Battery type 4000mAH 10000mAH 10000mAH 10000mAH 10000mAH
Upgrade 3 Years 3 Years 3 Years 3 Years 3 Years

Xtool D9 has made a breakthrough in hardware and runs faster. It can expand the range of detectable vehicles through the OBD2 connector kit.

  • ECU Coding and Online Coding+ Active test(Bi directional control)
  • OE All System Diagnostic
  • Calibration/Initialization/Matching/Relearn
  • Auto VIN/Auto Scan/VIN Scan/Manual VIN Input
  • Wireless BT Connection+Cables
  • 24*7 Online Tech Support
  • Support DoIP & CAN FD protocol and 90+ Brands Coverage & Multilingual,Widely Coverage of 90+ Car Brands which include 1000+ type of vehicles
  • Muti Language Options

Advanced ECU Coding: ECU Coding will open up more hidden personalized functions of your vehicle, such as closing the windows with the remote control, improving the vehicle performance, setting the folding function of the rear-view mirror, and you can also disable some annoying functions through EUC coding, such as changing the buzzer on the vehicle, disabling the safety warning sound and start/stop function, etc., to bring you a more comfortable driving experience.

ECU Coding Capability: Compatible with VW/AUDI/SKODA ONLY

Bi-Directional/Active Test: XTOOL D9 has a Bi-Directional control function. It can access vehicle subsystems and components through active testing, and then output commands through ECU to detect the integrity of vehicle systems and components, and find out the fault location and cause, such as evap test, cylinder deactivation, cycling a / C Clutch on / off, opening fuel injector, on / off, ABS motor pump for cycling, testing windows, doors, skylights, wipers, etc, So as to easily and effectively find out the fault location.

OE Level All Systems Diagnostic (Few minutes Read all systems): In order to better diagnose the vehicle, XTOOL D9 can realize the diagnosis and maintenance reset of all systems, including the vehicle ECU to read and clear DTCs, retrieve real-time data, freeze frames, ECU information, and perform active testing, matching, adaptation, turn off warning lights, and reset the monitor.

  • Reading ECU and Clear DTC
  • Retrieve Real-time Data
  • ECU information, and perform active testing, matching, adaptation, turn off warning lights, and reset the monitor
  • Freeze Frames

Auto VIN/Auto Scan/VIN Scan/Manual VIN Input:

  • Auto VIN: XTOOL D9 has the latest automatic VIN scanning function. It can identify vehicle information and scan all ECUs for diagnosis. This function is compatible with 2006 and new models.
  • Manual VIN Input: For vehicles not supporting the Auto VIN Scan function, you may manually enter the vehicle VIN.
  • Automatic Selection: The Auto VIN Scan can be selected after selecting the test vehicle manufacturer.
  • Manual Selection: When the vehicle's VIN is not automatically retrievable through the vehicle's ECU, or the specific VIN is unknown, the vehicle can be manually selected.
Powerful Key Programming Function:
  • Work with EEPROM Adapter (Package NOT Included) to read/write/backup the IMMO data
  • Read Pin~code
  • Add New Keys (Fob/Smart)
  • Remote Learning
  • Key Matching
  • Remote Learn
  • ALL-KEYS-LO*ST, etc
  • D9 Support Key programmer Functions can works with KC100 works for VW 4th and 5th immo .and KC501 for Benz infrared key
Intelligent Topology Module Mapping Capability:

Intuitive displays the relationship between vehicle systems to provide a more efficient method for today's complex in-vehicle communications, providing you with a clear view of your vehicle systems/modules and their working status.

XTOOL D9 comes with 35+ special maintenance services, covering all available reset functions:
  • Oil/Service/Maintenance Light
  • Gear Learning
  • Electric Parking Brake
  • DPF
  • Throttle Relearn
  • EEPROM Adapter
  • Window Initialization
  • Injector Coding
  • Tyre Pressure Reset
  • Airbag Repair
  • ABS Bleeding
  • Cylinder
  • Gearbox Match
  • Seat Configurations
  • Instrument Cluster
  • Electronic Pump Activation
  • BMS Reset
  • Performance Tire Upgrade
  • Air Suspension
  • Stop/start Reset
  • Steering Angle Sensor Adjustment
  • Language Change

Transmission Service Fast Relearn, Fuel Injector Balance, Crankshaft Sensors Relearn, Idle Learn, Zero- Point Calibration, Fuel Alcohol Composition Reset, Actuator Calibration Test, WCS Reset, VIN Registration(Write), Injector Balance Rate Programming, etc are all available.

Remote Technical Support: Customers can get remote support from XTOOL's team of technical engineers who control your device from their PC via TeamViewer software.

Maintenance Assistant: Includes how-to videos, how-to tips, user manuals, Q&A, quick start guides, and more.

Diagnosis History: Once a vehicle diagnosis is made, the XTOOL D9 will record every detail of the diagnosis process. You can record/view/playback real-time data at any time. The history function provides quick access to the vehicle under test and the user can resume the last operation without the need to start over.

Diagnostic Feedback: Allows you to submit any issues that cannot be fixed immediately. With the support of XTOOL professional experts, we will strive to provide you with the best solution as soon as possible.

Remote Diagnosis: Configuring XTOOL D9 as an I/M (Instant Messaging) tool makes it easier for technicians to exchange maintenance experience and provide remote assistance.

Vehicle Health Report Sharing and Printing: With XTOOL D9, you can generate a complete system diagnostic report with one click. Reports can be emailed to the office or sent directly to your clients. You can also print out a vehicle health report card.

One Click Update Online & Mutil Languages Support:

  • XTOOL D9 supports 3 years of free updates, you can get the latest version of the software, enjoy the latest technology and cover more new models.
  • After the 3-year free update service expires, XTOOL can still be used normally.
  • XTOOL D9 can support 15 kinds of language: English, Spanish, German, French, Italian, Finnish, Arabic, Japanese, Korean, Polish, Portuguese, Vietnamese, Russian, Simplified Chinese, and traditional Chinese.
